All Vantage riflescopes feature our H2 optics in a variety of configurations.
- Scope Tube: 30mm
- Magnification: 3 - 9x
- Objective Lens: 42mm
- Reticle: L4A Dot (2 MOA)
- Illumination: 5 Levels (Red & Green)
- Illumination Control: Stepped Rheostat
- Parallax: Fixed
- Focal Plane: SFP (Second Focal Plane)
- Lens Coating: Fully Multi-Coated - 11 Layers
- Optical System: System H2
- Field of View: 42.2 - 13.1ft @100yds/14.1 - 4.4m @100m
- Field of View (°): 8 - 2.5
- Eye Relief：3.5in/90mm
- PX/Focus：100yds/91m
- Click Value：1⁄ 4MOA
- Exit Pupil：0.55 - 0.19″/14 - 4.7mm
- Turret Type (Elevation)：Capped, Low-Profile, Resettable
- Elevation Turret Clicks (max)：120 MOA
- Turret Type (Windage)：Capped, Low-Profile, Resettable
- Windage Turret Clicks (max)：120 MOA
- Ocular Type：Fast Focus
- Power Selector：Knurled Posi-Grip
